It is meticulously designed based on the world’s advanced, mature, and reliable capacitive sensor technology, combined with advanced single-chip computer technology and sensor digital conversion technology. The core component adopts a 16-bit microcontroller, which ensures the excellent quality of the transmitter with its powerful functions and high-speed computing ability.

The powerful interface function ensures good interactivity without the need for manual manipulation. The digital LCD display head can display three physical quantities: pressure, temperature, and current, as well as 0-100% analog indication，key operation can easily complete basic parameter settings such as zero shift, range setting, and damping setting without a standard pressure source. Moreover, the transmitter can be recalibrated, greatly facilitating on-site debugging.

The integrated design of signal conversion, signal acquisition，processing, and current output control makes the structure more compact and reliable.

STANDARD PARAMETERS

Digital accuracy: 0.05%
Simulation accuracy: 0.075%~0.1% FS Full performance: ± 0.25% FS Stability: 0.25% FS for 60 months Range: 100:1
Measurement rate: 0.2s
Miniaturized (2.7kg) all stainless steel flange for easy installation
Process connection compatible with other products achieve optimal measurement
The sensor with H alloy sheath achieves excellent cold and thermal stability
Intelligent transmitter by using of 16-bit machine.
Standard (4~20) mA self-contained communication keyboard and RS-485 communication interface, without the need of manual operator support to fieldbus and based field control upgrade technology.
